60.5cm (23.8") Full HD 1920 x 1080 W-LED IPS, 16:9, 250cd/m², 16.7M, 6ms, 178°/178°, 1000:1
Key Features
- 60.5cm (23.8") Full HD 1920 x 1080 W-LED IPS
- 6ms, 16:9, 250cd/m², 1000:1
- USB, HDMI, DisplayPort
Description
Unparalleled collaboration. Quick installation.The ThinkCentre Tiny-In-One (TIO) 24 Gen 5 displays visuals and video content with great clarity on the 23.8-inch borderless In-Plane Switching FHD panel with 99% sRGB color support. It provides a complete working experience when paired with its VoIP features, a modular design which allows it to be attached with Lenovo’s range of high-performance ThinkCentre and ThinkStation Tiny Computers from 4th Gen. These can be effortlessly installed and housed in the dedicated slot at the back of the monitor, giving you a cable-free desk. Enjoy a consistent experience while using the classic installation mechanism to quickly and easily mount Tiny PCs to the monitor. Designed for efficient remote collaboration, it has a 1080p RGB webcam with a noise-cancellation microphone for i crystal-clear audio and video. Besides that, the Smart Traffic Light indicator indicates the status of an ongoing interaction or meeting, helping you avoid unforeseen distractions. Two integrated 3W user-facing speakers play the audio with amazing fidelity, making attending meetings a much more pleasant experience. Dedicated VoIP buttons allow you to easily mute or change the volume, making your remote meeting experience much more convenient. User-centric features like ThinkShutter allow you to cover your webcam lens for enhanced privacy and security. Recyclable packaging and optional CO2 offset service for minimal carbon emission footprint make this monitor environment-friendly. In addition to the Tiny PCs, you can also connect other laptops or towers using the HDMI and DP ports, and peripherals using the USB ports. The monitor’s Natural Low Blue Light technology works to reduce the harmful blue light without any color distortion during long working hours. Customize your workstation and easily adjust its various settings using the ThinkColour Software1. In a nutshell, the TIO 24 Gen 5 helps you get a clean, clutter-free desk, collaborate seamlessly and multitask efficiently to maximize productivity.
Specifications
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
6 W |
| Performance |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
6 W |
| Built-in microphone |
Yes |
| Built-in camera |
Yes |
| Compatible operating systems |
Windows 10
Windows 11 |
| Low Blue Light technology |
Yes |
| Display |
|---|
| Display brightness (typical) |
250 cd/m² |
| Screen shape |
Flat |
| Display number of colours |
16.7 million colors |
| Native aspect ratio |
16:9 |
| Pixel density |
93 ppi |
| Colour gamut |
99% |
| Maximum refresh rate |
60 Hz |
| sRGB coverage (typical) |
99% |
| HD type |
Full HD |
| Display technology |
LED |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
3000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.0108 x 0.0108" (0.275 x 0.275 mm) |
| Viewable size, horizontal |
20.7" (52.7 cm) |
| Viewable size, vertical |
11.7" (29.6 cm) |
| Backlight type |
W-LED |
| Display resolution |
1920 x 1080 pixels |
| Response time |
6 ms |
| Display diagonal |
23.8" |
| Response time (fast) |
4 ms |
| Touchscreen |
No |
| Panel type |
IPS |
| Colour depth |
8 bit |
| Colour gamut standard |
sRGB |
| Anti-glare screen |
Yes |
| Management features |
|---|
| On Screen Display (OSD) |
Yes |
| Multimedia |
|---|
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| RMS rated power |
6 W |
| Built-in microphone |
Yes |
| Built-in camera |
Yes |
| Power |
|---|
| Power cable length |
39.4" (1 m) |
| Power supply type |
External |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (max) |
34 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
14 W |
| Power consumption (off) |
0.5 W |
| Design |
|---|
| Feet colour |
Black, Red |
| Certification |
EPEAT Gold Registered
EU Energy Label (D-class)
ENERGY STAR Certified
TCO Certified 9.0
TCO edge 2.0
Volatile Organic Compound Certification
RoHS compliant
Eyesafe Certified 2.0
TÜV Rheinland Eye Comfort Certification
TÜV Rheinland Low Blue Light (Hardware Solution) |
| Product colour |
Black |
| Detachable stand |
Yes |
| Colour name |
Raven Black |
| Camera |
|---|
| Built-in camera |
Yes |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type |
USB Type-B |
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| HDMI |
Yes |
| HDMI version |
1.4 |
| DisplayPort version |
1.2 |
| Built-in KVM switch |
Yes |
| Technical details |
|---|
| Height (without stand) |
14.5" (367.6 mm) |
| Depth (without stand) |
2.87" (72.8 mm) |
| Width (without stand) |
21.3" (539.8 mm) |
| Feet colour |
Black, Red |
| Cable lock slot |
Yes |
| HDMI |
Yes |
| Built-in microphone |
Yes |
| Product colour |
Black |
| Compatible operating systems |
Windows 10
Windows 11 |
| Power supply type |
External |
| Weight (with stand) |
13.2 lbs (6 kg) |
| Touchscreen |
No |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Swivelling |
Yes |
| Swivel angle range |
-45 - 45° |
| Tilt angle range |
-5 - 23.5° |
| Pivot |
Yes |
| On Screen Display (OSD) |
Yes |
| Pivot angle |
-5 - 90° |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Cable management |
Yes |
| Tilt adjustment |
Yes |
| Adjustable height (max) |
6.1" (15.5 cm) |
| Weight & dimensions |
|---|
| Height (without stand) |
14.5" (367.6 mm) |
| Depth (without stand) |
2.87" (72.8 mm) |
| Width (without stand) |
21.3" (539.8 mm) |
| Width (with stand) |
21.3" (539.8 mm) |
| Depth (with stand) |
8.17" (207.6 mm) |
| Height (with stand) |
21.2" (539.6 mm) |
| Bezel width (side) |
0.0787" (2 mm) |
| Bezel width (top) |
0.0787" (2 mm) |
| Bezel width (bottom) |
1.81" (4.6 cm) |
| Weight (with stand) |
13.2 lbs (6 kg) |
| Weight (without stand) |
8.16 lbs (3.7 kg) |
| Package width |
24.4" (620 mm) |
| Package depth |
7.36" (187 mm) |
| Package height |
16.5" (420 mm) |
| Package weight |
20.9 lbs (9.5 kg) |
| Packaging data |
|---|
| Package width |
24.4" (620 mm) |
| Package depth |
7.36" (187 mm) |
| Package height |
16.5" (420 mm) |
| Package weight |
20.9 lbs (9.5 kg) |
| Stand included |
Yes |
| Power cable length |
39.4" (1 m) |
| Quick start guide |
Yes |
| Cables included |
AC |
| Power adapter included |
Yes |
| Packaging content |
|---|
| Stand included |
Yes |
| Power cable length |
39.4" (1 m) |
| Quick start guide |
Yes |
| Cables included |
AC |
| Power adapter included |
Yes |
| Other features |
|---|
| Compatible operating systems |
Windows 10
Windows 11 |
| Certification |
EPEAT Gold Registered
EU Energy Label (D-class)
ENERGY STAR Certified
TCO Certified 9.0
TCO edge 2.0
Volatile Organic Compound Certification
RoHS compliant
Eyesafe Certified 2.0
TÜV Rheinland Eye Comfort Certification
TÜV Rheinland Low Blue Light (Hardware Solution) |
| Height (without stand) |
14.5" (367.6 mm) |
| Depth (without stand) |
2.87" (72.8 mm) |
| Width (without stand) |
21.3" (539.8 mm) |
| Power consumption (max) |
34 W |
| Quick start guide |
Yes |
| HDMI |
Yes |
| Power supply type |
External |
| Power cable length |
39.4" (1 m) |
| Touchscreen |
No |
| Certificates |
|---|
| Certification |
EPEAT Gold Registered
EU Energy Label (D-class)
ENERGY STAR Certified
TCO Certified 9.0
TCO edge 2.0
Volatile Organic Compound Certification
RoHS compliant
Eyesafe Certified 2.0
TÜV Rheinland Eye Comfort Certification
TÜV Rheinland Low Blue Light (Hardware Solution) |
