23.8" In-Plane Switching, 1920x1080, 93 dpi, 60 Hz
Description
A monitor that's more than just another screen, ThinkVision T24 m-20 renders easy connectivity and manageability to businesses. Enjoy the generous screen space of 23.8 inches on this FHD In-Plane Switching panel. With 3-side NearEdgeless bezels and daisy-chaining capability via the DP-out port, enjoy an unrestricted view and multitasking in a multi-monitor setup. It is equipped with USB Type-C technology that provides rapid transfer speeds via a one-cable solution. For secure and reliable connectivity and remote management, an Ethernet port lets users work uninterrupted. Ergonomic features with a clutter-free, space-saving design can't go unnoticed on the T24 m, which makes for a comfortable work experience wherever the users are. The monitor also actively works to safeguard your eyes with TÜV Rheinland Eye Comfort, TÜV Low Blue Light (Hardware Solution) and Natural Low Blue Light technology with Eyesafe certification that reduce flicker and harmful high-energy blue light that could otherwise cause eye fatigue. With sustainable packaging using pulp cushion, the T24 m monitor remains environmentally friendly throughout its life cycle. With ThinkColour software, you can instantly and effortlessly adjust the fine controls of the monitor.
Specifications
| Display |
|---|
| Display brightness (typical) |
250 cd/m² |
| Screen shape |
Flat |
| Display number of colours |
16.7 million colors |
| Native aspect ratio |
16:9 |
| Colour gamut |
72% |
| Maximum refresh rate |
60 Hz |
| HD type |
Full HD |
| Display technology |
LED |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
3000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.0108 x 0.0108" (0.275 x 0.275 mm) |
| Viewable size, horizontal |
20.7" (52.7 cm) |
| Viewable size, vertical |
11.7" (29.6 cm) |
| Backlight type |
W-LED |
| Display resolution |
1920 x 1080 pixels |
| Response time |
6 ms |
| Display diagonal |
23.8" |
| Response time (fast) |
4 ms |
| Touchscreen |
No |
| Panel type |
IPS |
| Colour depth |
8 bit |
| Colour gamut standard |
NTSC |
| Anti-glare screen |
Yes |
| Management features |
|---|
| On Screen Display (OSD) |
Yes |
| Performance |
|---|
| Low Blue Light technology |
Yes |
| Design |
|---|
| Certification |
ENERGY STAR
CCC
TCO 8.0
EPEAT Gold
TÜV |
| Product colour |
Black |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type |
USB Type-C |
| USB Type-A downstream ports quantity |
4 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
2 |
| Audio output |
Yes |
| HDMI |
Yes |
| HDMI version |
1.4 |
| DisplayPort version |
1.2 |
| USB Power Delivery (USB PD) |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Number of USB Type-C upstream ports quantity |
1 |
| Ethernet LAN |
Yes |
| Technical details |
|---|
| Height (without stand) |
12.8" (325.9 mm) |
| Depth (without stand) |
1.75" (44.4 mm) |
| Width (without stand) |
21.3" (539.8 mm) |
| Cable lock slot |
Yes |
| HDMI |
Yes |
| Product colour |
Black |
| Weight (with stand) |
13.4 lbs (6.1 kg) |
| Touchscreen |
No |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Swivelling |
Yes |
| Swivel angle range |
-45 - 45° |
| Tilt angle range |
-5 - 35° |
| Pivot |
Yes |
| On Screen Display (OSD) |
Yes |
| Pivot angle |
-90 - 90° |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Cable management |
Yes |
| Tilt adjustment |
Yes |
| Adjustable height (max) |
5.91" (15 cm) |
| Power |
|---|
| AC input voltage |
90 - 264 V |
| AC input frequency |
50 - 60 Hz |
| Power consumption (max) |
140 W |
| Power consumption (typical) |
22 W |
| Power consumption (off) |
0.5 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
D |
| Energy consumption (SDR) per 1000 hours |
13 kWh |
| Weight & dimensions |
|---|
| Height (without stand) |
12.8" (325.9 mm) |
| Depth (without stand) |
1.75" (44.4 mm) |
| Width (without stand) |
21.3" (539.8 mm) |
| Width (with stand) |
21.3" (539.8 mm) |
| Depth (with stand) |
8.07" (204.9 mm) |
| Height (with stand) |
16.4" (417.1 mm) |
| Bezel width (side) |
0.0787" (2 mm) |
| Bezel width (top) |
0.0787" (2 mm) |
| Bezel width (bottom) |
0.866" (2.2 cm) |
| Weight (with stand) |
13.4 lbs (6.1 kg) |
| Weight (without stand) |
7.94 lbs (3.6 kg) |
| Package width |
23.8" (604 mm) |
| Package depth |
18.9" (480 mm) |
| Package height |
6.34" (161 mm) |
| Package weight |
19.6 lbs (8.9 kg) |
| Packaging data |
|---|
| Package width |
23.8" (604 mm) |
| Package depth |
18.9" (480 mm) |
| Package height |
6.34" (161 mm) |
| Package weight |
19.6 lbs (8.9 kg) |
| Other features |
|---|
| Certification |
ENERGY STAR
CCC
TCO 8.0
EPEAT Gold
TÜV |
| Height (without stand) |
12.8" (325.9 mm) |
| Depth (without stand) |
1.75" (44.4 mm) |
| Width (without stand) |
21.3" (539.8 mm) |
| Power consumption (max) |
140 W |
| HDMI |
Yes |
| Energy efficiency scale |
A to G |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Ethernet LAN |
Yes |
| Touchscreen |
No |
| USB Power Delivery (USB PD) |
Yes |
| Certificates |
|---|
| Certification |
ENERGY STAR
CCC
TCO 8.0
EPEAT Gold
TÜV |
