| Scanning |
|---|
| Output greyscale depth |
8 bit |
| Maximum scan size |
8.5 x 14" (216 x 356 mm) |
| Optical scanning resolution |
600 x 600 DPI |
| Colour scanning |
Yes |
| Duplex scanning |
Yes |
| Output colour depth |
24 bit |
| Greyscale levels |
256 |
| ADF scan speed (b/w, A4) |
30 ppm |
| ADF scan speed (colour, A4) |
30 ppm |
| Duplex ADF scan speed (b/w, A4) |
60 ipm |
| Duplex ADF scan speed (colour, A4) |
60 ipm |
| Sensor type |
CMOS CIS |
| Light source |
RGB LED |
| Daily duty cycle (max) |
3500 pages |
| Scan media weight |
27 - 209 g/m² |
| Design |
|---|
| Scanner type |
Sheet-fed scanner |
| Product colour |
Black |
| Performance |
|---|
| Sensor type |
CMOS CIS |
| Light source |
RGB LED |
| Daily duty cycle (max) |
3500 pages |
| Scan drivers |
ISIS, TWAIN |
| Input capacity |
|---|
| Standard input capacity |
60 sheets |
| Paper handling |
|---|
| Maximum scan width |
8.5" (21.6 cm) |
| Maximum scan length |
118.1" (3 m) |
| Maximum ISO A-series paper size |
A4 |
| Media thickness (min) |
0.00236" (0.0600 mm) |
| Scanning media types supported |
Business Card, Plastic Card |
| Multi feed detection |
Yes |
| Card thickness (max) |
0.0551" (1.4 mm) |
| Ports & interfaces |
|---|
| Standard interfaces |
USB 2.0 |
| USB port |
Yes |
| USB version |
2.0 |
| Software |
|---|
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
| Scan drivers |
ISIS, TWAIN |
| Power |
|---|
| Power consumption (typical) |
19 W |
| Power consumption (off) |
0.1 W |
| Input voltage |
100-240 V |
| Power supply type |
AC |
| Power consumption (sleep) |
1.4 W |
| AC input frequency |
50 - 60 Hz |
| Sleep mode |
Yes |
| Weight & dimensions |
|---|
| Width |
11.5" (291 mm) |
| Depth |
9.96" (253 mm) |
| Height |
9.09" (231 mm) |
| Weight |
6.17 lbs (2.8 kg) |
| Packaging content |
|---|
| Cables included |
AC, USB |
| AC adapter included |
Yes |
| Technical details |
|---|
| Maximum scan width |
8.5" (21.6 cm) |
| Media thickness (min) |
0.00236" (0.0600 mm) |
| Scanner type |
Sheet-fed scanner |
| Product colour |
Black |
| Sustainability certificates |
ENERGY STAR |
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR |
| System requirements |
|---|
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
10 - 32.5 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Other features |
|---|
| Scan media weight |
27 - 209 g/m² |
| Compliance certificates |
RoHS |
| Scanner type |
Sheet-fed scanner |
