Mobile Thermal Printer, A4, 256MB RAM, 203 dpi, 13.5 ppm, USB, 255(W) x 55(D) x 30(H) mm, 480 g
Key Features
- USB Type-C connectivity for data transfer and charging
- 203dpi print resolution
- Up to 13.5ppm print speed
- Android, Windows, Mac and Linux support
- Optional high-capacity Li-ion battery for printing away from power sources
- Customise your print solution with vehicle mounting kit, chargers and protective cases
Description
Print quotations, invoices, and other reports whilst on the move and streamline the work of field sales, field service, logistics, delivery and the emergency service sectors.
The PJ-822 with its USB connectivity offers a mobile A4 print solution compact enough to fit easily into a briefcase or computer bag, but that can also be permanently installed in vehicles.
Thermal print technology at 203x200dpi produces crisp text at a print speed of up to 13.5 pages per minute.
Compatible with a wide range of mobile and desktop operating systems, the PJ-822 can easily be integrated into your own apps and software using the various SDK's (Software Development Kits) available. Also supports a variety of printer command languages, including ZPL2 emulation.
Specifications
| Printing |
|---|
| Type |
Mobile printer |
| Print technology |
Direct thermal |
| Maximum resolution |
203 x 200 DPI |
| Printing characters |
2D barcode, Barcode, Text |
| Performance |
|---|
| Type |
Mobile printer |
| Print technology |
Direct thermal |
| Maximum resolution |
203 x 200 DPI |
| Built-in barcodes |
2D, AZTECCODE, Code 128 (A/B/C), Code 39, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, ITF, Industrial 2/5, MSI, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, Standard 2/5, UPC-A, UPC-E |
| Paper handling |
|---|
| Printing media thickness |
160 µm |
| Maximum printing width |
7.99" (20.3 cm) |
| Ports & interfaces |
|---|
| Connectivity technology |
Wired |
| USB port |
Yes |
| USB connector |
USB Type-C |
| Print technology |
|---|
| Type |
Mobile printer |
| Print technology |
Direct thermal |
| Print quality |
|---|
| Maximum resolution |
203 x 200 DPI |
| Maximum printing width |
7.99" (20.3 cm) |
| Technical details |
|---|
| Windows operating systems supported |
Yes |
| Mobile operating systems supported |
Android |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Maximum printing width |
7.99" (20.3 cm) |
| Product colour |
Black |
| Built-in barcodes |
2D, AZTECCODE, Code 128 (A/B/C), Code 39, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, ITF, Industrial 2/5, MSI, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, Standard 2/5, UPC-A, UPC-E |
| Products per pallet |
240 pc(s) |
| Layers per pallet |
8 pc(s) |
| Master (outer) cases per pallet |
48 pc(s) |
| Pallet gross weight |
515.9 lbs (234 kg) |
| Pallet gross height |
6.42" (16.3 cm) |
| Country of origin |
China |
| Master (outer) cases per pallet layer |
6 pc(s) |
| Pallet type |
800 x 1200 mm |
| Features |
|---|
| Internal memory |
256 MB |
| Flash memory |
64 MB |
| Product colour |
Black |
| Built-in barcodes |
2D, AZTECCODE, Code 128 (A/B/C), Code 39, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, ITF, Industrial 2/5, MSI, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, Standard 2/5, UPC-A, UPC-E |
| Country of origin |
China |
| Design |
|---|
| Product colour |
Black |
| Built-in display |
No |
| Display |
|---|
| Built-in display |
No |
| Memory |
|---|
| Internal memory |
256 MB |
| Flash memory |
64 MB |
| Power |
|---|
| Power source type |
USB |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Mobile operating systems supported |
Android |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Weight & dimensions |
|---|
| Width |
6.69" (170 mm) |
| Depth |
12.2" (310 mm) |
| Height |
2.95" (75 mm) |
| Package weight |
31.9 oz (904 g) |
| Weight |
20.5 oz (582 g) |
| Packaging data |
|---|
| Package weight |
31.9 oz (904 g) |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Mobile operating systems supported |
Android |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Logistics data |
|---|
| Products per pallet |
240 pc(s) |
| Layers per pallet |
8 pc(s) |
| Master (outer) cases per pallet |
48 pc(s) |
| Pallet gross weight |
515.9 lbs (234 kg) |
| Pallet gross height |
6.42" (16.3 cm) |
