Portable, A4, 15 ppm, 1200 x 1200 dpi, micro USB 3.0 Type B, 301 x 63 x 45.3 mm, 646 g
Key Features
- 2-sided A4 scanning up to 15 pages per minute
- Space saving ‘U-path’ paper feed system
- Industry leading software to scan documents, receipts and ID cards
- Power directly from a USB 3.0 port on PC
Description
DSmobile DS-740D 2-sided Portable Document ScannerScan 2-sided and go with the DSmobile DS-740D. Simple to use, this is a great choice for scanning when you are out of the office or where office space is limited.
Bring your documents to life with the DSmobile DS-740D portable document scanner.
Enjoy scanning, saving and sharing your files whether you are in the office or out on the road. Whether it's receipts, 2-sided documents or ID cards, your files are easily transformed into digital files. Making your information safer, easier to find and more convenient to edit or share.
The unique roller system means you are not required to have extra space behind the scanner for the document to feed-through. As the document goes in, it glides over the top of the scanner and is returned to you.
Specifications
| Scanning |
|---|
| Black/white scanning colour modes |
Grayscale, Monochrome |
| Maximum scan size |
8.5 x 72" (215.9 x 1828.8 mm) |
| Optical scanning resolution |
600 x 600 DPI |
| Enhanced scan resolution |
1200 x 1200 DPI |
| Colour scanning |
Yes |
| Duplex scanning |
Yes |
| Input colour depth |
48 bit |
| Output colour depth |
24 bit |
| Greyscale levels |
256 |
| Scan to |
E-mail, File, Image, OCR |
| Design |
|---|
| Built-in display |
No |
| Scanner type |
Sheet-fed scanner |
| Product colour |
Black, White |
| Performance |
|---|
| Scan to |
E-mail, File, Image, OCR |
| Scan drivers |
ICA, SANE, TWAIN, WIA |
| Scanning noise level |
53 dB |
| Internal memory |
256 MB |
| Sound pressure level (max) |
42 dB |
| Input capacity |
|---|
| Standard input capacity |
1 sheets |
| Paper handling |
|---|
| Maximum scan width |
8.5" (21.6 cm) |
| Maximum scan length |
72" (182.9 cm) |
| Maximum ISO A-series paper size |
A4 |
| Scanning media types supported |
Business Card, Plain paper, Plastic Card |
| Card thickness (max) |
0.0488" (1.24 mm) |
| Ports & interfaces |
|---|
| USB connector type |
Micro-USB B |
| Standard interfaces |
USB 3.2 Gen 1 (3.1 Gen 1) |
| USB port |
Yes |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Scan drivers |
ICA, SANE, TWAIN, WIA |
| Sound emission |
|---|
| Scanning noise level |
53 dB |
| Power |
|---|
| Power consumption (typical) |
2.9 W |
| Power consumption (standby) |
1.4 W |
| Power consumption (off) |
0.01 W |
| Power supply type |
USB |
| Weight & dimensions |
|---|
| Width |
6.38" (162 mm) |
| Depth |
2.99" (76 mm) |
| Height |
14.8" (377 mm) |
| Weight |
18.9 oz (537 g) |
| Package depth |
6.38" (162 mm) |
| Package weight |
2.58 lbs (1.17 kg) |
| Package width |
14.8" (377 mm) |
| Package height |
2.99" (76 mm) |
| Packaging data |
|---|
| Package depth |
6.38" (162 mm) |
| Package weight |
2.58 lbs (1.17 kg) |
| Package width |
14.8" (377 mm) |
| Package height |
2.99" (76 mm) |
| Quantity per pack |
1 pc(s) |
| Products per pallet |
240 pc(s) |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
Micro-USB |
| Warranty card |
Yes |
| Technical details |
|---|
| Maximum scan width |
8.5" (21.6 cm) |
| Pallet gross height |
6.57" (16.7 cm) |
| Black/white scanning colour modes |
Grayscale, Monochrome |
| Scanner type |
Sheet-fed scanner |
| Country of origin |
China |
| Product colour |
Black, White |
| Layers per pallet |
8 pc(s) |
| Master (outer) cases per pallet |
80 pc(s) |
| Master (outer) cases per pallet layer |
10 pc(s) |
| Harmonized System (HS) code |
84716070 |
| Pallet type |
800 x 1200 mm |
| Memory |
|---|
| Internal memory |
256 MB |
| Features |
|---|
| Country of origin |
China |
| System requirements |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Other features |
|---|
| Pallet gross weight |
630.5 lbs (286 kg) |
| Scanner type |
Sheet-fed scanner |
| Country of origin |
China |
| Products per pallet |
240 pc(s) |
| Layers per pallet |
8 pc(s) |
| Master (outer) cases per pallet |
80 pc(s) |
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Pallet gross weight |
630.5 lbs (286 kg) |
| Country of origin |
China |
| Products per pallet |
240 pc(s) |
| Layers per pallet |
8 pc(s) |
| Master (outer) cases per pallet |
80 pc(s) |
| Quantity per pack |
1 pc(s) |
| Pallet gross height |
6.57" (16.7 cm) |
| Master (outer) cases per pallet layer |
10 pc(s) |
| Harmonized System (HS) code |
84716070 |
