Brother TD-4420DN label printer Direct thermal 203 x 203 DPI 203 mm/sec Wired Ethernet LAN

203 x 203 dpi, 203 mm/sec, RS-232C, USB 2.0, 10/100Base-TX, 108 x 155 x 224 mm, 2.08 kg

Key Features

• Network connectivity
• High-quality up to 203dpi print resolution
• Fast print speeds up to 8 inches per second
• Print width up to 4.09 inches / 104mm
• Easy set-up with automatic media configuration
• Ready to integrate with iOS and Android apps

Description

TD-4420DN high-quality network desktop label printer

Print high-quality, continuous labels using media up to 118mm/4.65 inch wide. With built-in network for easy sharing.

With built-in network connectivity, the TD-4420DN is designed to be shared.

Labels are printed at a high-resolution, producing sharp and clear images. Making the TD-4420DN ideal for printing 1D barcodes for scanning.

Direct thermal print technology produces accurate images, with crisp definition. Utilising heat-sensitive coating, ink is not required. A good choice for printing high-volume, temporary labels with barcodes with a maximum media width up to 118mm/4.65 inches wide.

Network connectivity

Increase your teams productivity with this network desktop label printer. Sharing is made easier with the integrated network port.

Seamless integration

Understanding that integration into legacy systems is important, many printer command languages are supported. Including ZPL II emulation, Raster, CPCL emulation and many more.

Print from your Windows PC

Custom labels are easily created using Brother's P-touch Editor. Add your company logo, symbols to hundreds of built-in images to the labels you create. Not to mention, linking your excel data to print large batches of labels.

Software support

Brother provides the tools for developers to integrate their printing applications. Printer drivers are available for Windows Operating Systems. Software Development Kits are available to embed label printing into existing software programs

Healthcare, medical and laboratory

With the strict regulations on the tracking of patient specimens and other items within the healthcare industry, clear, high quality labelling is essential to maintain safety and traceability.

Warehousing and logistics

Efficient warehousing operation and worker productivity are critical to the success of many companies. With the most common sizes of shipping labels available and the ability to create custom size labels, there are many uses for these models in the warehouse.

Retail

Easy to read labels are essential for consumers to help make informed decisions prior to a potential purchase. The high print resolution and high quality labels used in this range ensure that every output printed looks professional, offering sharp text, logos and barcodes with a high contrast to ensure faultless scanning at the checkout.

Specifications

Print quality
Maximum resolution	203 x 203 DPI
Maximum print height	4.09" (10.4 cm)
Printing
Date & time printing	Yes
Text style	Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround
Colour	No
Print speed	203 mm/sec
Print speed	8 lpm
Maximum resolution	203 x 203 DPI
Maximum print height	4.09" (10.4 cm)
Print technology	Direct thermal
Mirror printing	Yes
Maximum print length	118.1" (3 m)
Design
LED indicators	Error, Power, Status
Display	No
Product colour	Gray, White
Built-in display	No
Display
Display	No
Network
Wi-Fi	No
Ethernet LAN	Yes
Memory
Internal memory	256 MB
Flash memory	64 MB
Paper handling
Maximum roll diameter	5" (12.7 cm)
Maximum label width	4.65" (11.8 cm)
Core diameter	0.5" (1.27 cm)
Ports & interfaces
USB 2.0 ports quantity	1
RS-232 ports	1
Connectivity technology	Wired
Bluetooth	No
Wi-Fi	No
Ethernet LAN	Yes
USB port	Yes
Performance
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Languages support	Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
Number of languages	18
Number of fonts	6
Internal memory	256 MB
Flash memory	64 MB
Page description languages	ESC P, Raster_P, ZPL II
Font styles	Brougham,Brussels,Helsinki,Letter Gothic,San Diego
Power
Auto power off	Yes
Technical details
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Warranty card	Yes
Product colour	Gray, White
Number of fonts	6
Maximum label width	4.65" (11.8 cm)
LED indicators	Error, Power, Status
Country of origin	China
Products per pallet	40 pc(s)
Layers per pallet	5 pc(s)
Master (outer) cases per pallet	40 pc(s)
Mirror printing	Yes
Font styles	Brougham,Brussels,Helsinki,Letter Gothic,San Diego
Harmonized System (HS) code	84433210
Pallet type	800 x 1200 mm
System requirements
Mobile operating systems supported	Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Linux operating systems supported	Yes
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Operational conditions
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	20 - 85%
Operating temperature (T-T)	10 - 90 °C
Operating relative humidity (H-H)	5 - 40%
Weight & dimensions
Width	10.4" (265 mm)
Depth	13.2" (335 mm)
Height	10.1" (256 mm)
Weight	6.83 lbs (3.1 kg)
Package weight	8.86 lbs (4.02 kg)
Packaging data
Package weight	8.86 lbs (4.02 kg)
Quantity per pack	1 pc(s)
Packaging content
Software development kit (SDK)	Yes
AC adapter included	Yes
Warranty card	Yes
Quick start guide	Yes
Cables included	AC, USB
Starter roll included	Yes
Quantity per pack	1 pc(s)
Other features
Products per pallet	40 pc(s)
Layers per pallet	5 pc(s)
Master (outer) cases per pallet	40 pc(s)
Quantity per pack	1 pc(s)
Date & time printing	Yes
Languages support	Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
Number of languages	18
LED indicators	Error, Power, Status
Country of origin	China
Spare part retention	5 year(s)
Logistics data
Pallet gross height	5.63" (14.3 cm)
Master (outer) cases per pallet layer	8 pc(s)
Pallet gross weight	388.9 lbs (176.4 kg)
Products per pallet	40 pc(s)
Layers per pallet	5 pc(s)
Master (outer) cases per pallet	40 pc(s)
Harmonized System (HS) code	84433210
