EIZO FlexScan EV3450XC-BK computer monitor 34.1" 3440 x 1440 pixels UltraWide Quad HD LCD Black

34.1" UWQHD (3440 x 1440), 3800R, sRGB, 300 cd/m², 5 ms, 1000:1, HDMI, DisplayPort, USB, RJ-45, KVM, 23 W

Key Features

• 34.1"" curved ultrawide monitor with 21:9 format and 3440x1440 pixels (109 ppi) for excellent readability
• 5 MP webcam, microphone with noise canceling, integrated speaker and audio connection
• Docking function via USB-C with DisplayPort signal, LAN and power supply up to 94 watts
• Signal inputs: USB-C (DisplayPort Alt Mode), DisplayPort, dual HDMI
• Auto EcoView, EcoView Index and EcoView Optimizer for maximum energy savings and optimum ergonomics
• KVM switch and picture-in-picture operation for up to 2 computers/signal sources
• Optionally in black or white housing color
• Demonstrably environmentally conscious and socially responsible production
• 5-year warranty for maximum investment security

Description

The EIZO FlexScan EV3450XC is optimized for the demands of the modern working world. With an integrated, high-resolution 5MP webcam, built-in microphone with noise and echo cancellation and feedback-free speakers, it is fully equipped for video conferencing. In addition, the curved ultrawide screen with a 34.1" diagonal, 21:9 format and UWQHD resolution (3440 x 1440 pixels) offers an extra large screen area for demanding applications or intensive multitasking. The webcam and infrared sensor support Windows Hello for convenient and secure unlocking of the computer using facial recognition. The EV3450XC’s USB-C docking connects video, audio and USB data signals and charges laptops with 94 watts of power. The integrated LAN port enables stable online conferences. Image reproduction with the EV3450XC is sharp, clear, fast and flicker-free. When scrolling and positioning windows or images, the readable display appears in fractions of a second - faster than it can be perceived. Power consumption and energy efficiency are always in view. This also applies to colors, which are displayed in sRGB free of oversaturation. Equipped in this way, the EV3450XC is ideally tailored to the challenges of companies that rely on hybrid forms of work with a combination of office work and remote work.

Specifications

Display
HDCP	Yes
Display brightness (typical)	300 cd/m²
Screen shape	Curved
Display number of colours	16.7 million colors
Native aspect ratio	21:9
Pixel density	109 ppi
Maximum refresh rate	60 Hz
HD type	UltraWide Quad HD
Display technology	LCD
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Pixel pitch	0.00917 x 0.00917" (0.233 x 0.233 mm)
Viewable size, horizontal	31.5" (80 cm)
Viewable size, vertical	13.2" (33.5 cm)
Digital horizontal frequency	31 - 89.5 kHz
Digital vertical frequency	29.5 - 61 Hz
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3440 x 1440
Backlight type	W-LED
Display resolution	3440 x 1440 pixels
Response time	5 ms
Display diagonal	34.1"
Touchscreen	No
Panel type	IPS
Screen curvature rating	3800R
Display diagonal (metric)	34.1" (86.7 cm)
LED backlight	Yes
Colour gamut standard	sRGB
Anti-glare screen	Yes
Audio
Built-in speaker(s)	Yes
RMS rated power	8 W
Performance
Built-in speaker(s)	Yes
RMS rated power	8 W
Megapixel (approx.)	5 MP
Built-in microphone	Yes
Built-in camera	Yes
AMD FreeSync	No
NVIDIA G-SYNC	No
Low Blue Light technology	Yes
Flicker-free technology	Yes
Management features
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	German, English, Spanish, French, Italian, Swedish
Network
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Multimedia
Number of speakers	2
Built-in speaker(s)	Yes
RMS rated power	8 W
Megapixel (approx.)	5 MP
Built-in microphone	Yes
Built-in camera	Yes
Design
Market positioning	Office
Feet colour	Black
Product colour	Black
Camera
Megapixel (approx.)	5 MP
Built-in camera	Yes
Ports & interfaces
Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B, USB Type-C
Number of upstream ports	2
USB Type-A downstream ports quantity	2
USB Type-C downstream ports quantity	1
Headphone out	Yes
HDMI ports quantity	2
DisplayPorts quantity	1
HDCP	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
HDMI	Yes
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	94 W
USB Type-C DisplayPort Alternate Mode	Yes
Number of USB Type-B upstream ports quantity	1
Number of USB Type-C upstream ports quantity	1
Built-in KVM switch	Yes
HDCP version	1.4/2.3
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Technical details
Height (without stand)	15.2" (385 mm)
Depth (without stand)	4.06" (103.1 mm)
Width (without stand)	32.3" (819.5 mm)
Feet colour	Black
HDMI	Yes
Built-in microphone	Yes
Product colour	Black
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, EPEAT Climate +, EPEAT Gold, TCO
Warranty period	5 year(s)
Compliance certificates	CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), GS mark, PSE, RCM, RoHS, TÜV mark, UKCA, VCCI
Weight (with stand)	26.7 lbs (12.1 kg)
Touchscreen	No
Ergonomics
VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Swivelling	Yes
Swivel angle range	-90 - 90°
Tilt angle range	-5 - 35°
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	German, English, Spanish, French, Italian, Swedish
Height adjustment	Yes
Tilt adjustment	Yes
Adjustable height (max)	7.68" (19.5 cm)
Picture-by-Picture (PbP)	Yes
Power
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	222 W
Power consumption (standby)	0.4 W
Power consumption (typical)	23 W
Power consumption (off)	0 W
Energy efficiency scale	A to G
Energy efficiency class (SDR)	F
Energy consumption (SDR) per 1000 hours	25 kWh
European Product Registry for Energy Labelling (EPREL) code	1960822
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Height (without stand)	15.2" (385 mm)
Depth (without stand)	4.06" (103.1 mm)
Width (without stand)	32.3" (819.5 mm)
Width (with stand)	32.3" (819.5 mm)
Depth (with stand)	9.53" (242 mm)
Height (with stand)	16.3" (414.5 mm)
Weight (with stand)	26.7 lbs (12.1 kg)
Weight (without stand)	20.3 lbs (9.2 kg)
Packaging content
Stand included	Yes
Quick start guide	Yes
Cables included	AC, DisplayPort, USB Type-C to USB Type-C, USB Type-A to USB Type-B
Sustainability
European Product Registry for Energy Labelling (EPREL) code	1960822
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR, EPEAT Climate +, EPEAT Gold, TCO
Packaging data
Stand included	Yes
Quick start guide	Yes
Cables included	AC, DisplayPort, USB Type-C to USB Type-C, USB Type-A to USB Type-B
Other features
Ethernet LAN data rates	10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
Picture-by-Picture (PbP)	Yes
Automatic brightness control	Yes
Warranty period	5 year(s)
Look-up table (LUT) bit depth	14
Compliance certificates	CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), GS mark, PSE, RCM, RoHS, TÜV mark, UKCA, VCCI
Height (without stand)	15.2" (385 mm)
Depth (without stand)	4.06" (103.1 mm)
Width (without stand)	32.3" (819.5 mm)
Power consumption (max)	222 W
Quick start guide	Yes
HDMI	Yes
USB Power Delivery up to	94 W
Energy efficiency scale	A to G
USB Type-C DisplayPort Alternate Mode	Yes
Ethernet LAN	Yes
Touchscreen	No
USB Power Delivery (USB PD)	Yes
Logistics data
Harmonized System (HS) code	85285210
