4-port USB 2.0 CAT 5 Extender (100m)
Key Features
- True USB 2.0 transparent extension over CAT 5 cabling up to 100 meters
- Supports all USB 2.0 devices up to 480Mbps
- USB Lossless – Higher compatibility of remote USB devices
- An integrated four port hub allows for extension of up to four USB devices without the need for an additional hub
- Power supply for remote unit to ensure power delivery to multiple devices at once
- Compact size with wall mounting and din rail included for flexible installation
- DC jack lock kit included to ensure durable power adapter connection
- Supports Windows®, OS X®, and Linux®
- Plug-and-play
Description
The UCE32100 is a 4-port USB 2.0 CAT 5 Extender is a two-unit device that serves as a Transmitter and a Receiver. It provides a durable, high quality connection that harnesses the full capability of the USB 2.0 standard, to ensure reliable data communication.
The UCE32100 can extend the USB transmission distance of up to 100 meters from your computer via a Cat 5 Ethernet cable. The power supply at the receiver UCE32100 unit helps provide sufficient power to any type of USB device, such as POS, flash drives, webcams, scanners, or printers, etc.
A true plug-and-play solution, the UCE32100 is compatible with all leading operating systems. With its durable metal housing, this high-quality USB extender provides a fast and flexible solution for industrial applications. In addition, the compact size with wall mounting and din rail included enables space-saving installation.
Specifications
| Technical details |
|---|
| Type |
Console transmitter & receiver |
| LED indicators |
Yes |
| Housing material |
Metal |
| Data transfer rate |
25 Mbit/s |
| Cable types supported |
Cat5 |
| Maximum transfer distance |
3937" (100 m) |
| Product colour |
Black |
| Ethernet LAN |
Yes |
| Harmonized System (HS) code |
84733020 |
| Ports & interfaces |
|---|
| RJ-45 ports quantity |
1 |
| USB 2.0 Type-B ports quantity |
1 |
| USB 2.0 Type-A ports quantity |
4 |
| Weight & dimensions |
|---|
| Width |
3.11" (79 mm) |
| Depth |
4" (101.5 mm) |
| Height |
0.961" (24.4 mm) |
| Weight |
7.41 oz (210 g) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Colour |
|---|
| Product colour |
Black |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Mounting kit |
Yes |
| Manual |
Yes |
| Cables included |
AC, USB |
| Power |
|---|
| Power source type |
DC |
| Input voltage |
5 V |
| Logistics data |
|---|
| Harmonized System (HS) code |
84733020 |
